Class Leading Bulk
Feed and Grain Samplers –
Manufactured by TEKPRO
“Samplex grain sampling machines are in operation throughout the world. They are reliable, long-lasting, and provide a truly representative sample from top to bottom of a bulk load.”
CS6000
The CS6000 truck probe is the latest addition to the Samplex range, It has the ability to sample a wide variety of products, and with tracked movement, has a maximum coverage of upto 35 metres.
CS90
The CS90 truck probe is our best selling sampler, it has the ability to sample a wide range of products and features telescopic movement.
CS30
The CS30 truck probe is our most basic sampler, which has limited features for simple operation, suited for smaller grain sites
Samplex Truck Probes
All Samplex grain samplers are built exclusively by TEKPRO Ltd; manufactured continuously for over 30 years in the UK. They have a unique gravity fed sampling system and variable aperture control, giving a truly representative sample from the full depth of the load. Our truck probes are built using durable materials with an electro-mechanical construction, which eliminates high pressure hydraulic hoses.
CS6000
Track mounted
Bulk Truck Probe
- Dry powders and milled products
- Seeds
- Cereals
- Pulses
- Animal feed pellets
- Wood pellets
- Made in Britain by TEKPRO
- Movement along track for longer vehicles
(14m, 21m, 28m or 35m coverage) - Able to reach corners
- Bottom of load detection
- Programmable automatic control
- 340° rotation
- Dual lane capability
- Accurate and Reliable
- Galvanised Steel
- 3PH 400V available only
Samplex CS6000 Information Sheet
Email my download link to:
The CS6000 truck probe can be used to sample a variety of products and is ideal for high throughput facilities receiving materials in long vehicles, and is useful for reaching all parts of a vehicle.
The innovative spear design ensures product enters the spear under gravity, providing a representative sample, which is important for testing.
The 340° rotation and track movement
Samples are automatically transported to a
All Samplex truck probes are made from
A range of different models
CS90
Telescopic
Bulk Truck Probe
- Made in Britain by TEKPRO
- Telescopic arm
- Bottom of load detection
- Programmable automatic control
- 340° rotation
- Dual lane capability
- Accurate and Reliable
- Galvanised Steel
- Electro-mechanical, no hydraulics
- 3PH 400V or 1PH 230V versions available
- Dry powders and milled products
- Seeds
- Cereals
- Pulses
- Animal feed pellets
- Wood pellets
Samplex CS90 Information Sheet
Email my download link to:
The CS90 truck probe can be used to sample a variety of products, and is used in high throughput facilities worldwide.
The patented spear design ensures product enters the spear under gravity, providing a representative sample, which is important for testing. The 340° rotation and extendable arm allows for variable sampling patterns, required to meet ISO 24333:2009 (E) standards. Samples are automatically transported to a reception chamber with a transparent viewing tube to allow for instant viewing.
All Samplex truck probes are made from galvanised steel, meaning they last for a long time without rusting. The CS90 has been on the market since 1989 with some of the original machines still in use today.
“The CS90 sampler has really simplified our entire sampling procedure. It is a straightforward design, easy to operate and considerably quicker than manually sampling a lorry. The sampler looks after itself – it doesn’t even require cleaning.”
Lucy McCririck, Intake Quality Controller, John Hogarth Limited
Bulk sampling from Train Wagons as well as sampling from road trucks is possible with Samplex samplers!
CS30
Fixed Arc
Truck Probe
- Made in Britain by TEKPRO
- Bottom of load detection
- Simple manual control
- 340° rotation
- Dual lane capability
- Accurate and Reliable
- Galvanised Steel
- Electro-mechanical, no hydrualics
- 3PH 380v-415v only
Samplex CS30 Information Sheet
Email my download link to:
The CS30 truck probe / grain sampler can be used to sample a selection of products and is ideal for low throughput facilities.
The patented spear design ensures product enters the spear under gravity, providing a representative sample, which is important for testing.
The 340° rotation allows for a variety of samples to be taken along the arms movement curve.
Samples are automatically transported to a reception chamber with a transparent viewing tube to allow for instant viewing.
All Samplex truck probes are made from galvanised steel, meaning they last for a long time without rusting.
Designed and exclusively Made in Britain by TEKPRO
Samplex has been the brand leader in the truck probe market for over 25 years. All our grain sampler systems are designed and manufactured by us at our UK base. This ensures all our products are built to the highest standards. Samplex grain samplers are in operation throughout the world. They are known for their reliability and long working life, and for providing a truly representative sample of a bulk load.
